DESIGN BASICS

Ever wonder why it is necessary to add framing in the corners and the edges of an older metal buildings when reroofing?

It is because of the differences in the Pre-2002 building code and the new building code. Old code buildings have roofs designed with a uniform loads unlike today’s buildings.

Older Building Code Roof Plan (1-1/2:12 Pitch or Less)
Current IBC 2015/ASCE 7-10 Building Code Roof Wind Zone Plan (1-1/2:12 Roof Pitch or Less), divides the roof into zones and each zone has it’s own design pressure.
Latest Version of IBC 2018/ASCE 7-16 Building Code Wind Zone Roof Plans

Although not widely adopted at this time, the 2018 IBC will further increase the number of roof zones for Wind and Snow loads. See drawings to the left.

NEED HELP?  CALL Roof Hugger, we will review the current building code in your area and estimate the wind and snow loading requirements. Third-party engineering is available to produce permit drawings and confirm all loads.

Roof Hugger has designed corner and edge framing on top of the existing roof panels to reduce the purlin spacing and correctly support the new panels to meet the higher design loads.

By using a combination of structural members running upslope (Sub-Rafters) and parallel to the existing purlins (Sub-Purlins) spaced to provide proper panel support, the proper loading is achieved. Once out of the high load zone we transition back to the easy to install Roof Hugger Sub-Purlins. In many cases where we have tested assemblies, the Sub-Rafters can be made to fit inside the Roof Hugger cutouts lowering the overall framing height and project cost. We call this system “Integral Framing”.

Roof Hugger sub-purlins have the ability to add strength to the existing purlins. This is important because most retrofit systems just add weight.

The drawing above shows how the Roof Hugger assembly is secured with our unique attachment system which typically strengthens the existing purlins. Roof Huggers strengthen the purlins allowing them to easily handle the additional retrofit weight.

ENERGY SAVING SOLUTIONS

Adding Insulation

When you install ROOF HUGGERS, the air space between the existing old roof and the bottom side of the new roof is well suited to install insulation for increasing the building’s thermal resistance. This is a very effective and inexpensive measure to save those energy dollars. Case studies have shown between 21% to 25% reduction in heating and cooling cost per year. (Each case is different and depends on the building’s occupancy and locale.)

Typically, fiberglass blanket insulation of varying thicknesses is installed but many building owners and design professionals will opt for rigid insulation. Both examples shown.

HOW DOES ABOVE SHEATHING VENTILATION (ASV) SYSTEM DYNAMICS WORK?

The illustration to the right represents a re-roofing assembly that employs both new insulation, radiant barrier and ASV dynamic ventilation for High-R systems with thermal resistance as much as R-50.

ENERGY EFFICIENT RETROFIT ASSEMBLIES

Retrofitting a roof with Roof Hugger creates any number of possibilities for improving the energy efficiency of an existing building. The height of the Roof Huggers can be specified to accommodate any thickness of fiberglass or rigid insulation. Above sheeting ventilation can be incorporated, glycol tube heat recovery coils can be added, high efficiency tall clip standing seam panels can be used and bracket or laminate photovoltaic panels can easily be added on the new panels without panel penetrations. If photovoltaic systems are to be added, typical 40-60 year life metal roofing is the only roof system that will outlast the useful life of the photovoltaic panels. This eliminates the huge cost of photovoltaic removal, re-roofing and reinstallation of the photovoltaic system typically required at the 15-20 year mark for conventional roofing materials.

Actual photo of Goodfellow AFB San Angelo, TX fully integrated retrofit roof system with mock-up photo shown below. The entire new roof assembly included a High R-Value insulation system (increased from R-19 to R-51.9), laminated solar photovoltaics for power generation and solar hot water system to furnish preheated water to building’s boiler.

TESTING AND PRODUCT APPROVALS

Prior to new panel installation for ASTM E1592 testing
Reinforced corner zone test assembly

E-1592 TESTING OF STANDING SEAM PANELS OVER ROOF HUGGERS

ATSM E 1592 test with pressure being applied
Testing after panel failure
OTHER ROOF HUGGER TESTING INCLUDES:
  • Screw down over screw down panel systems
  • Standing seam over standing seam systems
  • Standing seam over screw down systems
  • Reinforced gusseted systems
  • Drag load testing
  • Roll-over testing
  • 9 Florida Product Approved Assemblies
  • 1 Factory Mutual Tested Assembly
  • Base load testing
  • Diaphragm testing
ROOF HUGGER IS SPECIFIED AND USED BY:
  • United States Air Force, Army, Coast Guard, Corps of Engineers, Marine Corps, Navy and NASA with over 3-Million Square Feet of Facility Roofs
  • State and Local Governments
  • Port Authorities and Warehousing
  • National Airlines and Local Aircraft Hangar Facilities
  • Mini-Storage Complexes
  • Churches and Education Facilities
  • Utility Companies
  • Retail Sales and Auto Dealerships

When you compare retrofit framing systems, look at the test data. Calculated load capacity test data is not the same as ACTUAL laboratory test data for notched framing members.

THINGS TO REMEMBER
  • THE NEW ROOF PANEL WILL ALWAYS CONTROL THE FRAMING DESIGN. (Weaker panels typically require more framing than a stronger panels)
  • DIFFERENT PANELS MAY REQUIRE DIFFERENT FRAMING SOLUTIONS; FOR THE SAME BUILDING.
  • THE MOST ECONOMICAL DESIGN USES PANELS THAT CAN MEET THE LOADS IN ZONES 1 & 2. This design, if workable, restricts additional framing to the corner Zones only.
  • COMPARE THE INSULATION THICKNESS REQUIREMENTS TO THE DEPTH OF THE REQUIRED FRAMING MEMBERS FOR CONFLICT.

INSTRUCTIONAL VIDEOS

Roof Hugger Animated Installation Video

This video, of course, is an Artist’s rendered view of how simple Roof Huggers are installed. It illustrates the sequence of installation from installing our sub-rafters that are commonly included for wind uplift conditions in the corners and edges of the roof. These are not always required, but Roof Hugger will determine their need based on a preliminary design using your chosen new roof system’s E1592 test results. Then the eave Hugger is installed working your way up slope to the primary Huggers over the existing purlins and adding intermediate Huggers between the existing purlins. Our sub-rafters allow these intermediate Huggers to securely fasten to the new roof’s sub-framing system and satisfy building code required wind requirements. Insulation is installed during the new roof installation process if the building owner and roofing contractor chooses to include it. Installation of a Roof Hugger Metal-over-Metal Retrofit sub-framing system is Safe and Easy to understand.

E 1592 wind uplift testing over roof hugger sub-purlins

A short video to illustrate the negative pressure testing of a 16″ wide x 2″ tall vertical rib standing seam roof installed over Hugger sub-purlins attached to a simulated existing 12-inch O.C. “R” or PBR-Panel metal roof.

Video Location: Force Engineering & Testing Laboratories in Humble, Texas

THE DO'S AND DON'TS OF RETROFIT ROOFING

There are a number of ways that existing metal roofs have been and still are being retrofitted. Many of these methods cannot be considered structurally correct sub-framing systems. They lack the ability to withstand wind uplift and therefore are subject to failure. Roof Hugger sub-framing systems have been installed on over 100 million square feet of existing metal roofs and continue to be installed on approximately 6 million square feet annually. Our systems have withstood hurricane force wind loads from Katrina, Ike and others without a single failure. This is a testament to our systems that they are safe and structurally correct. This is the primary reason why Roof Hugger is the most specified metal-over-metal sub-framing systems by building owners nationwide including federal and state governments, the military and schools. Below are some of the other methods which we have listed their challenges.

Because of the width of the hat section, only one screw can be installed into the existing purlin. The other screw is attached to the existing 26 to 29 gauge metal, which does not provide sufficient pull-out strength.

Sitting on top of the existing ribs requires a long attachment screw and when exposed to thermal movement, they will “rock” back and forth causing fastener back out and ultimate failure.

Roof Huggers provide a positive connection directly to the existing purlins made available by our factory punched and nesting design.

For the same reasons as #1

Quantity of fasteners for the new metal roof must be increased due to the much reduced pull-out strength into wood, increasing installation labor and material costs.

Pressure treated wood is corrosive when placed in contact with existing and new metal roofs.

If 18 or 22 gauge hat sections are used in lieu of wood, as shown in the above isometric view, these members increase new metal roof fasteners due to low pull-out strength.

Roof Huggers are made from minimum 16 gauge grade 55 steel.

Unless the manufacturer of the stand-off clips has a manner to provide required additional sub-framing in the edges and corners of the existing roof, this method is challenged to withstand the increased wind loads in these zones by only attaching to the existing purlins.

Roof Huggers come with additional sub-framing, project engineered to meet wind loads up to and over 155 MPH wind speeds.

Most coatings are quick fixes that fail to permanently fix the existing roof.

Preparation of the existing roof is vital to the coating’s performance.

They do not comply with new stringent Building Code wind speeds.

Roof Huggers provide you with a new metal roof with a 50-plus year service life.

Read more about coatings:

TPO systems have become popular recently since they are slightly less expensive than Metal over Metal Systems.

Design and attachment is critical however. In order to meet existing wind loads the TPO must be connected to the existing purlins per the manufacturers approved and tested details. Systems that are attached only to the existing roof panels, will not comply with the codes.

TPO systems must not allow water to accumulate on the roof surface or overloading and potential collapse is possible (see photo).

TPO systems do nothing to add strength to the existing roof to meet the new code requirements for snow drifting they just add weight.

TPO systems have about half the life span of metal roofing systems, making their slight initial cost advantage a very poor investment.

Roof Huggers provide you with a base for a new long-life metal roof that can comply with all new wind and snow loads. Huggers also create a cavity that can be used to add insulation for increasing the buildings energy efficiency.

Read more about TPO systems: https://secureservercdn.net/104.238.68.196/666.cfa.myftpupload.com/docs/ProfessionalRoofingMetalToTheMetal.pdf

Roof Hugger sub-purlins are specifically designed to fit over any existing metal roof system.

They are much faster, less complex and less expensive than removing and replacing an old metal roof.

They can be made to a specific height for adding insulation or removing steps in roofs that have created poor weather tight roof connections.

They can add strength to the existing purlins to overcome the additional weight of the retrofit.

They can be designed to allow the new roof to comply with todays stricter building code requirements.

Roof Hugger is the most tested retrofit sub-framing System available. They are made from high strength 16ga. (0.060 min.), 50 ksi, G-90 Galvanized steel.

They will allow an existing screw-down metal roof to be upgraded to a standing seam roof without a major engineering analysis and upgrading the existing purlin bracing to make up for the removal of the diaphragm strength provided by the old roof panels.

Roof Hugger products are made in the USA
